Middle East

• Region: Middle East
• Topics: All Topics
• Date: Feb, 2017

This Video of the Month is from a well in the Middle East. The operator utilized EV’s Optis™ HD Memory camera to inspect the flow tube and flapper valve condition of a surface-controlled safety valve. Earlier intervention work had resulted in the need to fish tools at the valve but now the functionality of the valve was in question. There was communication across the valve but there was no access through it.

First, the operator decided to run a Lead Impression Block, which returned to surface with a half-moon shape impression. After seeing the impression, the Operator was not satisfied the results were conclusive and wanted a visual answer to identify what the obstruction was down hole.

EV were called in as an urgent service to give a clear answer. EV’s Optis™ HD colour memory camera capable of capturing 30 frames per second for up to 4 hours was deployed on Slickline to investigate. Once the camera program had completed, tools were pulled out of hole, footage was quickly downloaded and all soon became apparent.

The video shows the tubing had parted just below the DHSV. The camera exits the upper section of parted tubing and continues to run in. 4m below, the lower section of the parting can be seen, answering the half-moon shape on the LIB. With the assistance of the collapsible bowspring centralizers, the 1 11/16” OD toolstring was able to re-enter the lower section of tubing and continued to run in a further few meters.

While Pulling out of hole the camera exits the lower section of parting and re-enters the upper section of tubing capturing the DHSV components found to be in good condition.

The quick reaction from call-out to wellsite for EV to run EV their Optis™ Memory Camera allowed a definitive answer to the problem downhole in a matter of hours, saving the operator vital time & cost from making further unnecessary runs in hole, instead allowing them to plan ahead for the problem at hand.

• Region: Middle East
• Topics: All Topics
• Date: Jan, 2017

This Video of the Month is from a well in the Middle East. The operator utilized EV’s Optis™ HD Memory camera to inspect the flow tube and flapper valve condition of a surface-controlled safety valve. Earlier intervention work had resulted in the need to fish tools at the valve but now the functionality of the valve was in question. There was communication across the valve but not access through it.

EV’s HD memory camera was deployed on slickline and here we find the actuated flow tube shifting up and down properly while the camera is stationary. The operator prepped the well by pumping clear water and shutting the well in to allow a gas phase to build at this shallow depth from the surface. On the same camera run but one meter deeper is the flapper valve which should open as the flow tube is cycled. However, the flapper is jammed in a partly open position allowing fluid to pass by but not equipment.

The operator decided to mill through the flapper with a hydraulic workover unit and requested EV’s HD memory camera to check milling progress if there were issues. The flapper valve was successful milled through but a subsequent gauge run stacked out 32m below the valve. The camera was deployed to inspect the milled area of the safety valve and the cause of the deeper obstruction. The video shows a very clean milling job in the flapper area with no potential hazards to hang up tools. 32m deeper we find part of the milled flapper has fallen and is now stuck across the well bore. The operator elected to install a temporary safety valve and return the well to production and will attempt to recover the fish at a later date.
